Eltex ME5100 [179/670] Network
![Eltex ME5000 [179/670] Network](/views2/1569351/page179/bgb3.png)
Командный режим
config-router-ospfv2-area-interface
config-router-ospfv2-virtual-interface
config-router-ospfv2-vrf-area-interface
config-router-ospfv2-vrf-virtual-interface config-router-ospfv3-area-interface
config-router-ospfv3-virtual-interface
config-router-ospfv3-vrf-area-interface
config-router-ospfv3-vrf-virtual-interface
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# area 0.0.0.0
0/ME5100:example_router01(config-area)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# mtu-ignore
0/ME5100:example_router01(config-tengigabitethernet)#
11.42. network
Данная команда позволяет задать используемый тип интерфейса.
Отрицательная форма команды возвращает значение по умолчанию (broadcast).
Синтаксис
network { broadcast | loopback | nbma | point-to-multipoint | point-to-point | undefined }
no network
Параметры
• broadcast — широковещательная сеть со множественным доступом;
• loopback — loopback интерфейс;
• nmba — сеть множественного доступа без широковещательных доменов;
• point-to-multipoint — сеть типа "точка-многоточка";
• point-to-point — сеть типа "точка-точка".
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2-area-interface
config-router-ospfv2-vrf-area-interface
config-router-ospfv3-area-interface
config-router-ospfv3-vrf-area-interface
Пример
158
