Параметры
Команда не содержит аргументов
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2
config-router-ospfv2-vrf
config-router-ospfv3
config-router-ospfv3-vrf
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# advertise-max-metric
0/ME5100:example_router01(config-ospfv2)#
11.4. area
Данная команда создает в конфигурации устройства определенную зону OSPFv2 и позволяет
перейти в режим настройки конфигурации этой зоны. В режиме конфигурации зоны
возможно, в первую очередь, непосредственно конфигурировать интерфейсы, которые
будут участвовать в процессе маршрутизации OSPFv2.
Отрицательная форма команды удаляет данную area.
Синтаксис
[no] area AREA
Параметры
• AREA — значение OSPFv2 area в формате IPv4-адреса.
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2
config-router-ospfv2-vrf
config-router-ospfv3
config-router-ospfv3-vrf
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# area 0.0.0.0
0/ME5100:example_router01(config-area)#
131
