config-router-bgp-vrf-address-family-ipv6-unicast-redistribution-local
config-router-bgp-vrf-address-family-ipv6-unicast-redistribution-ospf
config-router-bgp-vrf-address-family-ipv6-unicast-redistribution-static
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# redistribution connected Redist-Connected
0/ME5100:example_router01(config-connected)# set extcommunity so value 10.0.0.1:65535
0/ME5100:example_router01(config-connected)# set extcommunity rt value 65535:100
0/ME5100:example_router01(config-connected)# no set extcommunity rt value
13.80. set local-preference
Команда назначает локальный приоритет (local preference) маршрутам,
перераспределенным в BGP RIB из другого протокола через указанное правило
редистрибуции.
Отрицательная форма команды отменяет назначение local preference.
Синтаксис
set local-preference INTEGER
no set local-preference
Параметры
• INTEGER — значение local preference. Диапазон допустимых значений: 0..4294967295.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-address-family-ipv4-unicast-redistribution-connected
config-router-bgp-address-family-ipv4-unicast-redistribution-isis
config-router-bgp-address-family-ipv4-unicast-redistribution-local
config-router-bgp-address-family-ipv4-unicast-redistribution-ospf
config-router-bgp-address-family-ipv4-unicast-redistribution-static
config-router-bgp-address-family-ipv6-unicast-redistribution-connected
config-router-bgp-address-family-ipv6-unicast-redistribution-isis
config-router-bgp-address-family-ipv6-unicast-redistribution-local
config-router-bgp-address-family-ipv6-unicast-redistribution-ospf
config-router-bgp-address-family-ipv6-unicast-redistribution-static
config-router-bgp-vrf-address-family-ipv4-unicast-redistribution-connected
config-router-bgp-vrf-address-family-ipv4-unicast-redistribution-isis
config-router-bgp-vrf-address-family-ipv4-unicast-redistribution-local
config-router-bgp-vrf-address-family-ipv4-unicast-redistribution-ospf
config-router-bgp-vrf-address-family-ipv4-unicast-redistribution-static
config-router-bgp-vrf-address-family-ipv6-unicast-redistribution-connected
313
