2. КОМАНДЫ ПОЛЬЗОВАТЕЛЬСКОГО
ИНТЕРФЕЙСА
2.1. change-privilege
Данной командой осуществляется переход на соответствующий уровень привилегий.
Синтаксис
change-privilege { p1 | p2 | … | p15 } [ PASSWORD ]
Параметры
• PASSWORD — пароль для перехода на требуемый уровень.
Необходимый уровень привилегий
p1
Командный режим
GLOBAL
Пример
0/ME5100:example_router01> change-privilege p15 mypassword
0/ME5100:example_router01#
2.2. clear alarm
Данная команда очищает активные аварии в системе.
Синтаксис
clear alarm {all | ID }
Параметры
• all — очищаются все активные аварии
• ID — очищается авария с указанным идентификатором.
Необходимый уровень привилегий
p15
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# clear alarm 300
9
