0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# class-map CLASS-MAP-01
0/ME5100:example_router01(config-class-map)# match-mode all
0/ME5100:example_router01(config-class-map)# no match-mode
0/ME5100:example_router01(config-class-map)#
23.12. mpls-tc
Команда позволяет классифицировать MPLS трафик по полю EXP (Experimental Field, MPLS
Traffic Class) в заголовке пакета и входит в режим конфигурирования параметров данного
трафика. Данная команда так же позволяет определить пакеты, которые будут
модифицированы в указанном rewrite-map.
Отрицательная форма команды удаляет настройку.
Синтаксис
[no] mpls-tc EXP
Параметры
• EXP — значение Experimental Field (MPLS Traffic Class). Диапазон допустимых
значений: 0..7.
Необходимый уровень привилегий
p10
Командный режим
config-qos-mpls-to-dscp-ingress-map
config-qos-rewrite-map
config-qos-tc-map
Пример
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# tc-map 1
0/ME5100:example_router01(config-tc-map)# mpls-tc 7
0/ME5100:example_router01(config-mpls-tc)#
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# rewrite-map 1
0/ME5100:example_router01(config-rewrite-map)# mpls-tc 7
0/ME5100:example_router01(config-mpls-tc)#
23.13. mpls-to-dscp ingress map
Команда входит в режим ввода правил модификации DCSP передаваемых пакетов в
501
