![Eltex ME5100 [381/670] 1 set prepend as path](/views2/1569351/page381/bg17d.png)
no set nexthop
Параметры
• NEXTHOP — next-hop в формате IPv4 (A.B.C.D) или IPv6 (X:X:X:X::X) адреса
Необходимый уровень привилегий
p10
Командный режим
config-route-map-seq-num
Пример
0/ME5100:example_router01(config)# route-map Test
0/ME5100:example_router01(config-route-map)# seq-num 10
0/ME5100:example_router01(config-seq-num)# set nexthop 10.0.0.1
0/ME5100:example_router01(config-seq-num)#
13.102.41. set prepend as-path
Команда задает значение номера AS, которое будет добавлено в начало пути AS Path
маршрутов, удовлетворяющих условиям указанного правила route-map. Количество таких
дополнений задается командой set prepend times.
Отрицательная форма команды удаляет настройку.
Синтаксис
set prepend as-path ASNUM
set prepend as-path { last-as | own-as }
no set prepend as-path
Параметры
• ASNUM — произвольный номер автономной системы (ASN) (1-4294967295, 1-65535:1-
65535);
• last-as — номер автономной системы из начала пути;
• own-as — номер собственной автономной системы.
Необходимый уровень привилегий
p10
Командный режим
config-route-map-seq-num
Пример
360
