Eltex ME5100 [508/670] Destination port eq
![Eltex ME5100 [508/670] Destination port eq](/views2/1569351/page508/bg1fc.png)
• IPv4_WILDCARD — IPv4-префикс в формате wildcard (A.B.C.D/A.B.C.D)
• any — не задано, в правило попадает пакет с любым IP-адресом назначения.
Необходимый уровень привилегий
p10
Командный режим
config-ipv4-access-list-entry
Пример
0/FMC0:example_router01(config)# ipv4 access-list List1
0/FMC0:example_router01(config-access-list)# entry 10
0/FMC0:example_router01(config-entry)# destination 10.0.0.0/0.0.0.255
0/FMC0:example_router01(config-entry)#
22.3. destination-port eq
Команда задает значение порта назначения пакета для сравнения в правиле списка досупа.
Отрицательная форма команды удаляет условие.
Синтаксис
destination-port eq NUMBER
no destination-port eq
Параметры
• NUMBER — номер порта (0..65535)
Необходимый уровень привилегий
p10
Командный режим
config-ipv4-access-list-entry
Пример
0/FMC0:example_router01(config)# ipv4 access-list List1
0/FMC0:example_router01(config-access-list)# entry 10
0/FMC0:example_router01(config-entry)# destination-port eq 80
0/FMC0:example_router01(config-entry)#
22.4. dscp
Команда задает значение DSCP пакета для сравнения в правиле списка досупа.
Отрицательная форма команды удаляет условие.
487
