Eltex ME5100 [562/670] Version
![Eltex ME5100 [562/670] Version](/views2/1569351/page562/bg232.png)
Синтаксис
[no] source-ip IPv4_ADDRESS
Параметры
• IPv4_ADDRESS — адрес в формате IPv4.
Необходимый уровень привилегий
p10
Командный режим
config-router-vrrp-interface
Пример
0/ME5100:example_router01(config)# router vrrp interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# source ip 192.168.0.2
0/ME5100:example_router01(config-tengigabitethernet)#
25.9. timers advertise
Команда задает временной интервал между отправками служебных VRRP-Announcement.
Отрицательная форма команды возвращает значение по умолчанию (1).
Синтаксис
[no] timers advertise SECONDS
Параметры
• SECONDS — интервал отправки VRRP-Announcement в секундах (1-40).
Необходимый уровень привилегий
p10
Командный режим
config-router-vrrp-interface
Пример
0/ME5100:example_router01(config)# router vrrp interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# timers advertise 5
0/ME5100:example_router01(config-tengigabitethernet)#
25.10. version
Выбор версии протокола VRRP. Версия 3 не имеет обратной совместимости с версией 2.
Отрицательная форма команды возвращает использование версии по умолчанию (2).
541
