13.20. bgp fast-external-fallover disable
Команда выключает быстрый разрыв сессии для External BGP соседей подключенных
напрямую при падении соответствующего интерфейса. При этом сессия остается активной
до исчерпания таймера holdtime.
Отрицательная форма команды возвращает поведение по умолчанию, eBGP сессия рвется
сразу после падения интерфейса, к которому подключен сосед.
Синтаксис
[no] bgp fast-external-fallover disable
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp
config-router-bgp-vrf
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# bgp fast-external-fallover disable
0/ME5100:example_router01(config-bgp)# no bgp fast-external-fallover disable
13.21. bgp graceful-restart enable
Данная команда включает поддержку Graceful Restart для протокола BGP.
Отрицательная форма команды выключает поддержку Graceful Restart.
Синтаксис
[no] bgp graceful-restart enable
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp
config-router-bgp-vrf
270
