Eltex ME5100 [189/670] Redistribute disable
![Eltex ME5100 [189/670] Redistribute disable](/views2/1569351/page189/bgbd.png)
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# redistribution connected CONNECTED
0/ME5100:example_router01(config-connected)# priority 10
0/ME5100:example_router01(config-connected)#
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# area 0.0.0.0
0/ME5100:example_router01(config-area)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# priority 20
0/ME5100:example_router01(config-tengigabitethernet)#
11.56. redistribute disable
Данная команда отключает редистрибуцию для данного правила.
Отрицательная форма команды включает редистрибуцию для данного правила.
Синтаксис
[no] redistribute disable
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2-redistribution
config-router-ospfv2-vrf-redistribution
config-router-ospfv3-redistribution
config-router-ospfv3-vrf-redistribution
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# redistribution local local
0/ME5100:example_router01(config-local)# redistribute disable
11.57. redistribution
Данная команда создает правило для передачи маршрутов определенного происхождения
(другие протоколы маршрутизации, статические маршруты и т.п.) в процесс
маршрутизации OSPFv2. Механизм такой передачи также называется редистрибуцией.
168
