Eltex ME5100 [354/670] Timers keepalive
![Eltex ME5000 [354/670] Timers keepalive](/views2/1569351/page354/bg162.png)
13.97. timers keepalive
Команда задает интервал отправки Keepalive сообщений, отправляемых соседу. Интервал
задается в секундах. Задание нулевого значения holdtime, наравне с нулевым holdtime,
отключает механизм keepalives/holdtime.
Отрицательная форма команды возвращает значение по умолчанию (60).
Синтаксис
timers keepalive SECONDS
no timers keepalive
Параметры
• SECONDS — значение таймера Keepalive в секундах. Диапазон допустимых значений:
0..65535.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-neighbor
config-router-bgp-peergroup
config-router-bgp-vrf-neighbor
config-router-bgp-vrf-peergroup
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# neighbor 10.0.0.10
0/ME5100:example_router01(config-neighbor)# timers keepalive 30
0/ME5100:example_router01(config-neighbor)# no timers keepalive
13.98. ttl-security-min-ttl
Команда включает защитный механизм Generalized TTL Security Mechanism (GTSM, RFC
5082). Параметр задает минимальный IPv4 TTL (Time To Live), а в случае IPV6 - Hop Limit, для
входящих пакетов в указанной BGP сессии. Пакеты с меньшим значением будут
отброшены.
NOTE
Для вступления в силу изменений в данной команде необходима
переинициализация BGP сессии.
Отрицательная форма команды выключает проверку TTL для заданной сесси.
Синтаксис
ttl-security-min-ttl TTL
no ttl-security-min-ttl
333
