Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# neighbor 10.0.0.10
0/ME5100:example_router01(config-neighbor)# max-prefix-hold 120
0/ME5100:example_router01(config-neighbor)# no max-prefix-hold
13.54. max-prefixes
Команда задает максимально допустимое количество префиксов, принимаемых от соседа.
При достижении лимита сессия разрывается либо выводится предупредительное
сообщение в системный журнал, см. команду session-drop-warning.
Отрицательная форма команды возвращает значение по умолчанию (0), что снимает
ограничение.
Синтаксис
max-prefixes INTEGER
no max-prefixes
Параметры
• INTEGER — максимально допустимое количество префиксов. Диапазон допустимых
значений: 0..2147483647.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-neighbor
config-router-bgp-peergroup
config-router-bgp-vrf-neighbor
config-router-bgp-vrf-peergroup
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# neighbor 10.0.0.10
0/ME5100:example_router01(config-neighbor)# max-prefixes 1024000
0/ME5100:example_router01(config-neighbor)# no max-prefixes
13.55. maximum-paths
Команда задает количество рассчитываемых и устанавливаемых в RIB маршрутов (best
paths) до префикса в заданном Address Family. Данный параметр используется для расчета
как iBGP, так и eBGP маршрутов. Команда используется для режима BGP Additional Paths
(additional-paths).
293
