config-l2vpn-bridge-domain-autodiscovery-bgp-route-target
config-l2vpn-xconnect-group-p2p-autodiscovery-bgp-route-target
Пример
0/ME5100:example_router01(config)# l2vpn bridge-domain test
0/ME5100:example_router01(config-bridge-domain)# autodiscovery bgp
0/ME5100:example_router01(config-bgp)# route-target 100:200
0/ME5100:example_router01(config-route-target)# import
0/ME5100:example_router01(config-route-target)#
15.14. interface
В режимах конфигурации бридж-доменов (config-l2vpn-bridge-domain) и кросс-коннектов
(config-l2vpn-xconnect-group-p2p) данная команда позволяет указать интерфейс или
сабинтерфейс в качестве Attachment circuit для VPLS и VPWS соответственно.
Отрицательная форма команды удаляет данный интерфейс из Attachment circuit.
Синтаксис
[no] interface bundle-ether PORT[.SUBINTERFACE]
[no] interface fortygigabitethernet UNIT/DEVICE/PORT[.SUBINTERFACE]
[no] interface gigabitethernet UNIT/DEVICE/PORT[.SUBINTERFACE]
[no] interface hundredgigabitethernet UNIT/DEVICE/PORT[.SUBINTERFACE]
[no] interface tengigabitethernet UNIT/DEVICE/PORT[.SUBINTERFACE]
Параметры
• DEVICE — параметр, который отвечает за номер устройства;
• PORT — параметр, который отвечает за номер порта;
• SUBINTERFACE — параметр, который отвечает за номер субинтерфейса;
• UNIT — параметр, который отвечает за номер слота устройства.
Необходимый уровень привилегий
p10
Командный режим
config-l2vpn-bridge-domain
config-l2vpn-xconnect-group-p2p
Пример
0/ME5100:example_router01(config)# l2vpn bridge-domain test
0/ME5100:example_router01(config-bridge-domain)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-bridge-domain)#
395
