Eltex ME5100 [24/670] Работа с глобальным режимом
![Eltex ME5100 [24/670] Работа с глобальным режимом](/views2/1569351/page24/bg18.png)
Команда Режим Действие команды
logout
config, global-view Быстрый выход из сессии интерфейса
командной строки
do <command_sequence>
config Выполнение команды глобального режима
CLI (command_sequence) без выхода из
режима конфигурирования
root
config Выход на верхний уровень режима
конфигурирования
end
config Выход из любого уровня режима
конфигурирования в глобальный режим
quit
global-view Выход из сессии интерфейса командной
строки
1.3. Работа с глобальным режимом
В глобальном режиме интерфейса командной строки доступны команды просмотра
оперативного состояния системы (show-команды), команды управления компонентами
системы (например, reload, hw-module), запуска различных диагностических тестов и работы
с образами операционной системы.
Для уменьшения объема отображаемых данных в ответ за запросы пользователя и
облегчения поиска необходимой информации можно воспользоваться фильтрацией. Для
фильтрации вывода команд нужно добавить в конец командной строки символ "|" и
использовать одну из опций фильтрации:
• begin — выводить всё после строки, содержащей заданный шаблон;
• include — выводить все строки, содержащие заданный шаблон;
• exclude — выводить все строки, не содержащие заданный шаблон;
• count — произвести подсчёт количества строк в выводе команды.
При необходимости включить в шаблон поиска символ пробела необходимо заключить
весь шаблон в двойные кавычки.
Фильтры можно стекировать, указывая несколько фильтров через символы "|".
3
