![Eltex ME5100 [118/670] Duplex](/views2/1569351/page118/bg76.png)
команде show interface и в команде show interface description. При использовании в
описании символом пробела необходимо заключать строку-параметр в двойные кавычки.
Отрицательная форма команды удаляет описание для интерфейса.
Синтакисис
description STRING
no description
Параметры
• STRING — строка, которая будет использована как описание интерфейса.
Необходимый уровень привилегий
p10
Командный режим
config-interface-bundle-ether
config-interface-bundle-ether-sub
config-interface-fortygigabitethernet
config-interface-fortygigabitethernet-sub
config-interface-gigabitethernet
config-interface-gigabitethernet-sub
config-interface-hundredgigabitethernet
config-interface-hundredgigabitethernet-sub
config-interface-loopback
config-interface-mgmt
config-interface-tengigabitethernet
config-interface-tengigabitethernet-sub
Пример
0/ME5100:example_router01(config)# interface tengigabitethernet 0/0/6.16
0/ME5100:example_router01(config-tengigabitethernet-sub)# description TEST
0/ME5100:example_router01(config-tengigabitethernet-sub)#
8.9. duplex
Данная команда позволяет установить в конфигурации значение режима дуплекса для
физического интерфейса.
Отрицательная форма команды возвращает значение по умолчанию (auto).
Синтаксис
duplex { auto | full | half }
no duplex
Параметры
• auto — параметр, который позволяет использовать согласование режима дуплекса;
97
