Eltex ME5100 [355/670] Update source
![Eltex ME5100 [355/670] Update source](/views2/1569351/page355/bg163.png)
Параметры
• TTL — значение IPv4/TTL, IPv6/HopLimit (0..255)
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-neighbor
config-router-bgp-peer-group
config-router-bgp-vrf-neighbor
config-router-bgp-vrf-peer-group
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# neighbor 100.64.0.2
0/ME5100:example_router01(config-neighbor)# ttl-security-min-ttl 2
0/ME5100:example_router01(config-neighbor)#
13.99. update-source
Команда задает интерфейс (адрес) для BGP сессии.
Отрицательная форма команды удаляет настройки, при этом сессия будет устанавливаться
от адреса интерфейса, через который доступен сосед.
Синтаксис
update-source IPv4_ADDRESS_FORMAT
no update-source
Параметры
• IPv4_ADDRESS_FORMAT — адрес интерфейса в формате IPv4 адреса.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-neighbor
config-router-bgp-vrf-neighbor
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# neighbor 10.0.0.10
0/ME5100:example_router01(config-neighbor)# update-source 172.16.0.1
0/ME5100:example_router01(config-neighbor)# no update-source
334
