8.13. ipv4 address
Данная команда позволяет установить IPv4-адрес на интерфейсе.
Отрицательная форма команды удаляет IPv4-адрес с интерфейса.
Синтаксис
[no] ipv4 address IPv4_ADDRESS_PREFIXLEN
Параметры
• IPv4_ADDRESS_PREFIXLEN — значение IPv4-адреса и длины сетевой маски.
Необходимый уровень привилегий
p10
Командный режим
config-interface-bundle-ether
config-interface-bundle-ether-sub
config-interface-fortygigabitethernet
config-interface-fortygigabitethernet-sub
config-interface-gigabitethernet
config-interface-gigabitethernet-sub
config-interface-hundredgigabitethernet
config-interface-hundredgigabitethernet-sub
config-interface-loopback
config-interface-mgmt
config-interface-tengigabitethernet
config-interface-tengigabitethernet-sub
Пример
0/ME5100:example_router01(config)# interface tengigabitethernet 0/0/6.16
0/ME5100:example_router01(config-tengigabitethernet-sub)# ipv4 address 10.1.1.3/24
0/ME5100:example_router01(config-tengigabitethernet-sub)#
8.14. load-interval
Данная команда позволяет задать в конфигурации интервал для расчета загрузки на
интерфейсе.
Отрицательная форма команды возвращает значение по умолчанию (300).
Синтаксис
load-interval SEC
no load-interval
Параметры
• SEC — значение интервала в секундах.
101
