15.15. l2vpn bridge-domain
Бридж-домены являются одним из двух основных механизмов Layer2-коммутации на
устройстве. В бридж-домен допускается включение в качестве точек входа-выхода таких
элементов, как интерфейсы (attachment circuits), MPLS pseudowires и экземпляры
виртуальной коммутации (VFI). Сконфигурированный бридж-домен производит
коммутацию Ethernet-кадров между своими точками входа-выхода по общим принципам
Ethernet-коммутации согласно существующей внутри бридж-домена таблицы MAC-адресов.
Коммутация трафика внутри бридж-домена производится с сохранением, но без учета,
VLAN-тегов на основании MAC-адресов получателя в Ethernet-кадрах.
Отрицательная форма команды удаляет данный бридж-домен.
Синтаксис
[no] l2vpn bridge-domain STRING
Параметры
• STRING — имя Bridge Domain.
Необходимый уровень привилегий
p10
Командный режим
config
Пример
0/ME5100:example_router01(config)# l2vpn bridge-domain test
0/ME5100:example_router01(config-bridge-domain)#
15.16. l2vpn pw-class
Данная команда позволяет создать в конфигурации элемент Pseudowire Class, настройки
которого могут быть в дальнейшем использованы при конфигурировании Pseudowire.
Отрицательная форма команды удаляет данный элемент из конфигурации.
Синтаксис
[no] l2vpn pw-class STRING
Параметры
• STRING — имя Pseudowire Class, (0..16).
Необходимый уровень привилегий
p10
Командный режим
config
396
