8. НАСТРОЙКА ИНТЕРФЕЙСОВ
8.1. arp aging-time
Данная команда позволяет установить время жизни ARP-записей на указанном интерфейсе.
Отрицательная форма команды возвращает значение по умолчанию (240).
Синтаксис
arp aging-time MIN
no arp aging-time
Параметры
• MIN — время жизни ARP пакетов в минутах.
Необходимый уровень привилегий
p10
Командный режим
config-interface-bundle-ether
config-interface-bundle-ether-sub
config-interface-fortygigabitethernet
config-interface-fortygigabitethernet-sub
config-interface-gigabitethernet
config-interface-gigabitethernet-sub
config-interface-hundredgigabitethernet
config-interface-hundredgigabitethernet-sub
config-interface-tengigabitethernet
config-interface-tengigabitethernet-sub
Пример
0/ME5100:example_router01(config)# interface tengigabitethernet 0/0/6.16
0/ME5100:example_router01(config-tengigabitethernet-sub)# arp aging-time 6
0/ME5100:example_router01(config-tengigabitethernet-sub)#
8.2. bfd address-family destination
Данная команда позволяет задать IPv4/IPv6 адрес назначения для создания Bidirectional
Forwarding Detection сессии на агрегированном интерфейсе (microBFD).
Отрицательная форма команды удаляет из конфигурации IPv4/IPv6 адрес назначения
microBFD сессии.
Синтаксис
bfd address-family {ipv4 | ipv6} destination {IPv4_FORMAT | IPv6_FORMAT}
no bfd address-family {ipv4 | ipv6} destination
93
