0/ME5100:example_router01(config)# route-map Test
0/ME5100:example_router01(config-route-map)# seq 10
0/ME5100:example_router01(config-seq-num)# match ext-comm-list exact
0/ME5100:example_router01(config-seq-num)#
13.102.12. match ext-comm-list name
Команда задает ip-extcommunity для сравнения набора BGP extended community маршрута.
Точность совпадения задается командой match ext-comm-list exact
Отрицательная форма команды удаляет условие.
Синтаксис
match ext-comm-list name EXTCOMMLIST
no match ext-comm-list name
Параметры
• EXTCOMMLIST — имя списка ip-extcommunity (1..32)
Необходимый уровень привилегий
p10
Командный режим
config-route-map-seq-num
Пример
0/ME5100:example_router01(config)# route-map Test
0/ME5100:example_router01(config-route-map)# seq 10
0/ME5100:example_router01(config-seq-num)# match ext-comm-list name TestExtCommList
0/ME5100:example_router01(config-seq-num)#
13.102.13. match prefix-list destination
Команда задает имя списка prefix-list для сравнения address-атрибута маршрута.
Отрицательная форма команды удаляет условие.
Синтаксис
match prefix-list destination PREFIXLIST
no match prefix-list destination
Параметры
• PREFIXLIST — имя списка prefix-list (1..32)
Необходимый уровень привилегий
p10
343
