1. ОСНОВЫ РАБОТЫ С КОМАНДНОЙ
СТРОКОЙ
1.1. Командный интерфейс и доступ к устройству
Основным инструментом настройки и управления устройством является интерфейс
командной строки (CLI).
Учётной записью по умолчанию является admin с паролем password. Данной учётной
записью можно воспользоваться для авторизации на устройстве и получения доступа к
командному интерфейсу в процессе первоначальной настройки.
IMPORTANT
Операционная система устройства имеет систему разделения
привилегий пользователей. Пользователю admin по умолчанию
назначены максимальные привилегии - уровень p15.
Командный интерфейс устройства поддерживает функцию автоматического дополнения
команд. Эта функция активируется при нажатии клавиши табуляции <TAB>. Также
интерфейс командной строки имеет функцию контекстной подсказки. На любом этапе
ввода команды можно получить подсказку о следующих возможных элементах команды
путём ввода вопросительного знака <?>.
1.2. Режимы командного интерфейса и команды
навигации
Интерфейс командной строки имеет два основных режима — глобальный режим и режим
конфигурирования. Для удобства оператора при переходе между режимами меняется
приглашение командной строки.
Вид приглашения командной строки в глобальном режиме
0/ME5100:EOS#
Вид приглашения командной строки в режиме конфигурирования
0/ME5100:EOS(config)#
Таблица 2. Основные команды навигации и переходов в интерфейсе командной строки
Команда Режим Действие команды
configure
global-view Переход из глобального режима CLI в режим
конфигурирования
exit
config Переход на вышестоящий уровень
конфигурирования
