Eltex ME5100 [404/670] Show mpls ldp parameters
![Eltex ME5100 [404/670] Show mpls ldp parameters](/views2/1569351/page404/bg194.png)
0/ME5100:example_router01# show mpls ldp neighbors id 10.0.0.2:0
Thu Aug 24 11:06:05 2017
Ê Peer LDP Identifier: 10.0.0.2:0
Ê TCP connection: 10.0.0.2
Ê Label distribution method: downstream-unsolicited
Ê Loop Dection for Path Vectors limits: 0
Ê Current state: operational, role: active
Ê Last state change: 00h20m56s ago
Ê Discontinuity time: 00h21m11s ago
Ê LDP 1 Protocol is using
Ê The negotiated KeepAlive time: 7 secs
Ê Configured hold time: 40 secs
Ê The peer's advertised keepalive hold time: 40 secs
Ê Currently keepalive hold use: 40 secs
Ê Peer reconnect time: 0 secs, recovery time: 0 secs
Ê Maximum allowable length for LDP PDUs: 4096 octets
Ê Graceful Restart support: peer is false, local is false
Ê Stats:
Ê 0 unknown message count, 0 unknown tlv count
Ê Neighbors in current session:
Ê Peer address index: 4, next hop address: 100.64.24.0
Ê Peer address index: 3, next hop address: 100.64.23.0
Ê Peer address index: 1, next hop address: 10.0.0.2
Ê Peer address index: 2, next hop address: 100.64.12.1
0/ME5100:example_router01#
14.26. show mpls ldp parameters
Команда выводит подробную информацию о конфигурации протокола LDP. Указание
параметров позволяет фильтровать вывод по интерфейсам, соседям.
Синтаксис
show mpls ldp parameters [ interfaces [ INTERFACE ] | neighbors [ ipv4 NEIGHBOR ] ]
Параметры
• interfaces — информация по интерфейсам;
• neighbors — информация по соседям;
• INTERFACE — имя интерфейса или сабинтерфейса;
• NEIGHBOR — IPv4 адрес соседа.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
383
