Отрицательная форма команды возвращает поведение по умолчанию, при пересечении
System ID соседство не строится.
Синтаксис
[no] duplicate-ids stop-adjacency disable
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-isis
config-router-isis-vrf
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# duplicate-ids stop-adjacency disable
0/ME5100:example_router01(config-isis)#
12.12. ecmp
Данная команда задает максимальное количество равнозначных маршрутов (Equal-cost
multi-path routing - ECMP), полученных от протокола IS-IS.
Отрицательная форма команды возвращает значение по умолчанию (4).
Синтаксис
ecmp NUMBER
no ecmp
Параметры
• NUMBER — максимальное количество равнозначных маршрутов до префикса (1..32).
Необходимый уровень привилегий
p10
Командный режим
config-router-isis
config-router-isis-vrf
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# ecmp 2
0/ME5100:example_router01(config-isis)#
198
