11.60. route-calculation-max-delay
Команда задает задержку пересчета таблицы маршрутизации при изменении базы данных
OSPF LSDB.
Отрицательная форма команды возвращает значение по умолчанию (0). В этом случае при
каждом изменении в LSDB RIB пересчитывается сразу.
Синтаксис
route-calculation-max-delay MILLISECONDS
no route-calculation-max-delay
Параметры
• MILLISECONDS — задержка пересчета RIB в миллисекундах (0-2147483647)
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2
config-router-ospfv2-vrf
config-router-ospfv3
config-router-ospfv3-vrf
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# route-calculation-max-delay 100
0/ME5100:example_router01(config-ospfv2)#
11.61. route-tag
Команда задает тэг суммарным маршрутам типа LSA Type-5 при агрегировании маршрутов
типа LSA Type-7.
Отрицательная форма команды возвращает значение по умолчанию (0).
Синтаксис
route-tag TAG
no route-tag
Параметры
• TAG — числовое значение тэга (0-2147483647)
Необходимый уровень привилегий
p10
171
