Eltex ME5100 [173/670] Match prefix
![Eltex ME5100 [173/670] Match prefix](/views2/1569351/page173/bgad.png)
• isis-level1-internal — IS-IS Level 1 маршрут, полученный через анонс подсети;
• isis-level2-external — IS-IS Level 2 маршрут, полученный через редистрибуцию;
• isis-level2-internal — IS-IS Level 2 маршрут, полученный через анонс подсети.
• none — все типы маршрутов.
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2-redistribution-bgp
config-router-ospfv2-redistribution-isis
config-router-ospfv2-vrf-redistribution-bgp
config-router-ospfv2-vrf-redistribution-isis
config-router-ospfv3-redistribution-bgp
config-router-ospfv3-redistribution-isis
config-router-ospfv3-vrf-redistribution-bgp
config-router-ospfv3-vrf-redistribution-isis
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# redistribution bgp RULE
0/ME5100:example_router01(config-bgp)# path-type-filter bgp-external
0/ME5100:example_router01(config-bgp)#
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# redistribution isis RULE
0/ME5100:example_router01(config-isis)# path-type-filter isis-level1-internal
0/ME5100:example_router01(config-isis)#
11.34. match prefix
Данная команда создает в конфигурации устройства ограничение на использование
определенных IPv4-префиксов в определенном правиле редистрибуции. Разрешается
использовать в правиле редистрибуции указанный префикс и все входящие в него подсети.
Отрицательная форма команды разрешает использовать в данном правиле редистрибуции
все префиксы, которые есть в указанном протоколе.
Синтаксис
match prefix IPv4_PREFIX_FORMAT
no match prefix
Параметры
• IPv4_PREFIX_FORMAT - значение префикса в формате IPv4-подсети.
152
