Параметры
• WEIGHT - числовое значение веса (0..2147483647)
Необходимый уровень привилегий
p10
Командный режим
config-route-map-seq-num
Пример
0/ME5100:example_router01(config)# route-map Test
0/ME5100:example_router01(config-route-map)# seq-num 10
0/ME5100:example_router01(config-seq-num)# set weight value 1024
0/ME5100:example_router01(config-seq-num)#
13.102.46. type expanded
Команда задает расширенный тип элемента списка ip-community и входит в режим его
конфигурирования. Данный тип позволяет использовать регулярные выражения для
задания community.
NOTE данная команда является взаимоисключающей с командой type standard.
Отрицательная форма команды удаляет настройку.
Синтаксис
[no] type expanded
Параметры
Команда не содержит аргументов
Необходимый уровень привилегий
p10
Командный режим
config-ip-community-seq-num
Пример
0/ME5100:example_router01(config)# ip-community TestCommList
0/ME5100:example_router01(config-ip-community)# seq-num 10
0/ME5100:example_router01(config-seq-num)# type expanded
0/ME5100:example_router01(config-expanded)#
13.102.47. type expanded regular-expression
Команда добавляет регулярное выражение для extended community в элемент списка ip-
363
