no vrf
Параметры
• NAME — параметр, который определяет имя VRF, к которому будет привязан
интерфейс.
Командный режим
config-interface-bundle-ether
config-interface-bundle-ether-sub
config-interface-fortygigabitethernet
config-interface-fortygigabitethernet-sub
config-interface-gigabitethernet
config-interface-gigabitethernet-sub
config-interface-hundredgigabitethernet
config-interface-hundredgigabitethernet-sub
config-interface-loopback
config-interface-mgmt
config-interface-tengigabitethernet
config-interface-tengigabitethernet-sub
Пример
0/ME5100:example_router01(config)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# vrf TEST
0/ME5100:example_router01(config-tengigabitethernet)#
117
