Eltex ME5100 [124/670] Rewrite egress tag
![Eltex ME5100 [124/670] Rewrite egress tag](/views2/1569351/page124/bg7c.png)
0/ME5100:example_router01(config)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# mtu 1700
0/ME5100:example_router01(config-tengigabitethernet)#
8.16. rewrite egress tag
Данная команда позволяет задать в конфигурации интерфейса правило для манипуляции
VLAN-тегами для исходящих Ethernet-кадров интерфейса. Команда применима только для
интерфейсов, находящихся в режиме layer2-коммутации (т.е. на интерфейсах, на которых не
задан IP-адрес).
Отрицательная форма команды удаляет данное правило из конфигурации.
NOTE
В операциях replace значение VID равное 0 означает не производить
операций над тэгом
Синтаксис
rewrite egress tag exchange
rewrite egress tag pop { one | two }
rewrite egress tag push outer-vid VID [ outer-type TYPE [ inner-vid VID [ inner-type TYPE ] ]
rewrite egress tag replace outer-vid VID [ outer-type TYPE ] [ inner-vid { VID | remove } [
inner-type TYPE ] ]
no rewrite egress
Параметры
• inner-vid — параметр, который определяет внутренний VLAN-тег;
• outer-vid — параметр, который определяет внешний VLAN-тег;
• one — параметр, который обозначает количество удаляемых из кадра VLAN-тегов
(удаляется один тег);
• two — параметр, который обозначает количество удаляемых из кадра VLAN-тегов
(удаляется два тега);
• remove — параметр, при указании которого второй тег будет снят (удален) с пакета.
Параметр применяется только для операции replace;
• outer-type — EtherType внешнего тэга;
• inner-type — EtherType внутреннего тэга;
• TYPE — значение EtherType тэга (8100, 88a8, 9100);
• VID — соответствующее значение VLAN ID в теге, 0 - не производить операций над
тэгом.
Командный режим
config-interface-bundle-ether-sub
config-interface-fortygigabitethernet-sub
config-interface-gigabitethernet-sub
103
