Eltex ME5100 [353/670] Timers holdtime
![Eltex ME5100 [353/670] Timers holdtime](/views2/1569351/page353/bg161.png)
Командный режим
config-router-bgp-address-family-ipv4-unicast-aggregate-address
config-router-bgp-address-family-ipv6-unicast-aggregate-address
config-router-bgp-vrf-address-family-ipv4-unicast-aggregate-address
config-router-bgp-vrf-address-family-ipv6-unicast-aggregate-address
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# aggregate-address 192.168.0.0/16
0/ME5100:example_router01(config-aggregate-address)# summary-only
0/ME5100:example_router01(config-aggregate-address)# no summary-only
13.96. timers holdtime
Команда задает значение Hold Time для соседа в секундах. Это время, за которое сосед
должен прислать KEEPALIVE или UPDATE сообщение, чтобы сессия считалась активной.
Hold Time согласуется на этапе обмена OPEN сообщениями, выбирается меньшее из двух
значений. Задание нулевого значения holdtime, наравне с нулевым keepalive, отключает
механизм keepalives/holdtime.
Отрицательная форма команды возвращает значение по умолчанию (180).
Синтаксис
timers holdtime SECONDS
no timers holdtime
Параметры
• SECONDS — значение Hold Time в секундах. Диапазон допустимых значений: 0,
3..65535.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-neighbor
config-router-bgp-peergroup
config-router-bgp-vrf-neighbor
config-router-bgp-vrf-peergroup
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# neighbor 10.0.0.10
0/ME5100:example_router01(config-neighbor)# timers holdtime 90
0/ME5100:example_router01(config-neighbor)# no timers holdtime
332
