Синтаксис
optional-tlv { mgmt-addr | port-desc | system-cap | system-desc | system-name } { disable |
enable }
Необходимый уровень привилегий
p10
Командный режим
config-lldp-interface-agent
Пример
0/ME5100:example_router01(config-agent)# optional-tlv system-cap disable
21.10. port-id-type
Данная команда определяет, какой параметр будет передаваться в качестве
идентификатора интерфейса. По умолчанию - interface-name.
Синтаксис
port-id-type { interface-name | local | mac-address }
Необходимый уровень привилегий
p10
Командный режим
config-lldp-interface-agent
Пример
0/ME5100:example_router01(config-agent)# port-id-type interface-name
21.11. receive
Данная команда разрешает прием LLDP-пакетов на интерфейсе. По умолчанию прием LLDP-
пакетов разрешен.
Синтаксис
receive {disable|enable}
Необходимый уровень привилегий
p10
Командный режим
config-lldp-interface-agent
478
