Eltex ME5100 [259/670] Show isis fast reroute
![Eltex ME5200 [259/670] Show isis fast reroute](/views2/1569351/page259/bg103.png)
Синтаксис
show isis [ vrf { all | VRF_NAME } ] database [ detailed ]
Параметры
• VRF_NAME — имя Virtual Routing and Forwarding сущности;
• detailed — параметр для вывода детальной информации IS-IS LSDB.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# show isis database
Thu Apr 5 13:34:43 2018
Ê IS-IS Router eltex-test
Ê IS-IS level-2 link-state database
Ê LSP ID Sequence Checksum Lifetime (sec) PDU length Attributes
Ê --------------------- --------- --------- --------------- ----------- -----------
Ê 0000.0000.0001.00-00 0xd2 0x56b7 1016 41 level-2
Ê 0000.0000.0001.00-01 0xd2 0x33a3 1105 32 level-2
Ê 0000.0000.0001.00-02 0x4060 0x17b3 1185 164 level-2
Ê 0000.0000.0001.01-00 0xd9 0xbe1d 1123 53 level-2
Ê 0000.0000.0001.02-00 0xc 0x5355 842 53 level-2
Ê 0000.0000.0002.00-00 0x989 0xc587 889 41 level-2
Ê 0000.0000.0002.00-01 0x987 0xac6a 672 32 level-2
Ê 0000.0000.0002.00-02 0xcf8e 0x28b1 882 164 level-2
Ê 0000.0000.0003.00-00 0x1c46 0x4a7f 956 297 level-2
Ê 0000.0000.0003.02-00 0x2a8 0x44c3 591 62 level-2
Ê 0000.0000.0004.00-00 0x3dd 0x1fdd 962 41 level-2
Ê 0000.0000.0004.00-01 0x3de 0x6bb 875 32 level-2
Ê 0000.0000.0004.00-02 0x196e0 0x8fed 1199 134 level-2
Ê 0000.0000.0005.00-00 0x2a1 0xc3e4 589 80 level-2
Ê 0000.0000.0006.00-00 0x2a3 0x24ed 469 79 level-2
Ê Total LSPs: 15
0/ME5100:example_router01#
12.71. show isis fast-reroute
Данная команда отображает информацию, связанную с IS-IS IP LFA FRR.
Синтаксис
show isis fast-reroute [ ipv4 { IPv4_FORMAT } | ipv6 { IPv6_FORMAT } | summary ]
238
