Eltex ME5100 [42/670] Show system reload
![Eltex ME5200 [42/670] Show system reload](/views2/1569351/page42/bg2a.png)
0/ME5100:example_router01# show system inventory
Mon May 8 15:26:26 2017
Ê Hardware inventory information for chassis 0
Ê Main system module is ME5100
Ê Serial number: ME09000035
Ê MAC address: a8:f9:4b:8b:bb:a0
Ê Hardware version: 3v1
Ê Hardware revision: 1
Ê Module in power supply slot 1 is PM350-220/12
Ê Serial number: PM06001605
Ê Hardware version: 2v4
Ê Module in power supply slot 2 is not present
2.19. show system reload
Данной командой осуществляется просмотр информации о времени и причине
перезагрузки устройства или отдельных слотов для модульных устройств.
Синтаксис
show system reload
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
0/FMC0:example_router02# show system reload
Thu Feb 7 14:57:35 2019
Ê Location Restarted at Reload reason
Ê ------------ -------------------------- --------------
Ê 0/1 Wed Jan 30 12:44:13 2019 Reload by admin from 192.168.16.93 telnet
Ê 0/8 Wed Jan 30 12:44:11 2019 Reload by admin from 192.168.16.93 telnet
Ê 0/9 Wed Jan 30 12:44:12 2019 Reload by admin from 192.168.16.93 telnet
Ê 0/FMC0 Wed Jan 30 12:43:37 2019 Reload by admin from 192.168.16.93 telnet
Ê 0/FMC1 Wed Jan 30 12:43:33 2019 Reload by admin from 192.168.16.93 telnet
0/FMC0:example_router02#
21
