0/ME5100:example_router01# show interfaces tengigabitethernet 0/0/1
Tue Oct 3 05:23:20 2017
Ê tengigabitethernet 0/0/1 is up
Ê Interface index is 25
Ê Hardware is tengigabitethernet, address is a8:f9:4b:8b:2b:81
Ê Link is up for 19 hours, 55 minutes, 15 seconds
Ê Description is not set
Ê IPv4 address is null
Ê IPv6 address is null
Ê Interface is bound to VRF none
Ê Interface is in layer2 forwarding mode
Ê ARP aging time is 240 minutes
Ê Interface MTU is 1522
Ê Full, 10G, link type is auto, media type is 10G-Fiber
Ê Flow control is rx
Ê 300 seconds input rate is 0 bit/s
Ê 300 seconds output rate is 0 bit/s
Ê 300 seconds input unicast rate is 0 pps
Ê 300 seconds output unicast rate is 0 pps
Ê 300 seconds input multicast rate is 0 pps
Ê 300 seconds output multicast rate is 0 pps
Ê 300 seconds input broadcast rate is 0 pps
Ê 300 seconds output broadcast rate is 0 pps
Ê 0 packets input, 0 bytes received
Ê 0 broadcasts, 0 multicasts
Ê 0 input errors, 0 FCS
Ê 0 oversize, 0 internal MAC
Ê 3 packets output, 270 bytes sent
Ê 0 broadcasts, 3 multicasts
Ê 0 output errors, collisions
Ê 0 excessive collisions, 0 late collisions
Ê 0 symbol errors, 0 carrier, 0 SQE test error
0/ME5100:example_router01#
8.21. show interfaces counters
Данная команда выводит в табличном виде информацию по счётчикам интерфейсов.
Синтаксис
show interfaces counters
Параметры
Команда не содержит параметров.
Необходимый уровень привилегий
p2
106
