Eltex ME5100 [295/670] Bgp update delay
![Eltex ME5100 [295/670] Bgp update delay](/views2/1569351/page295/bg127.png)
13.27. bgp update-delay
Команда задает значение задержки между установлением первой сессии и началом
отправки маршрутов (UPDATE) в случае, если пересчет локальной BGP RIB еще не закончен.
Данная задержка позволяет стабилизировать Local RIB перед отправкой анонсов.
Отрицательная форма команды возвращает значение по умолчанию (120).
Синтаксис
bgp update-delay SECONDS
no bgp update-delay
Параметры
• SECONDS — значение задержки в секундах. Допустимый диапазон: 0-3600.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp
config-router-bgp-vrf
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# bgp update-delay 60
0/ME5100:example_router01(config-bgp)# no bgp update-delay
13.28. bgp update-groups enable
Команда включает механизм объединения соседей со схожими параметрами в группы, что
позволяет сэкономить память за счет уменьшения экземпляров таблиц исходящих
обновлений (апдейтов). При использовании данной команды существуют следующие
ограничения: * входящие ORF фильтры от соседей в update-group будут игнорироваться; *
для соседей в update-group не будет осуществляться проверка анонсируемых маршрутов на
совпадение next-hop с адресом соседа.
Отрицательная форма команды отключает объединение соседей в группы.
Синтаксис
[no] bgp update-groups enable
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
274
