Параметры
• RELAY_AGENT_NAME — строковое имя агента (1..255)
Необходимый уровень привилегий
p10
Командный режим
config
Пример
0/ME5100:example_router01(config)# relay-agent 1
0/ME5100:example_router01(config-relay-agent)#
26.5. vrf
Команда указывает экземпляр VRF, к которому принадлежит указанный helper-address.
Отрицательная форма команды возвращает поведение по умолчанию, helper-address
принадлежит глобальной таблице (GRT).
Синтаксис
vrf VRF_NAME
no vrf
Параметры
• VRF_NAME — строковое имя экземпляра VRF (1..31)
Необходимый уровень привилегий
p10
Командный режим
config-relay-agent-address-family-ipv4-helper-address
config-relay-agent-address-family-ipv6-helper-address
Пример
0/ME5100:example_router01(config)# relay-agent 1
0/ME5100:example_router01(config-relay-agent)# address-family ipv4 helper-address
10.0.0.1
0/ME5100:example_router01(config-helper-address)# vrf Test
0/ME5100:example_router01(config-helper-address)#
545
