Необходимый уровень привилегий
p1
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# quit
Connection closed by foreign host.
2.8. redundancy switchover
Данной командой производится принудительное переключение ролей MASTER/SLAVE
между резервируемыми модулями управления и коммутации устройства. Команда
действует только на системах с двумя модулями управления и коммутации.
Синтаксис
redundancy switchover
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p15
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# redundancy switchover
CAUTION
Принудительное переключение ролей MASTER/SLAVE на системах с двумя
модулями управления и коммутации может привести к прерываниям
трафика. Данную команду следует использовать с крайней
осторожностью. Команда не снабжена диалогом подтверждения.
2.9. reload system
Данная команда осуществляет полную перезагрузку маршрутизатора. Команда имеет
диалог подтверждения. Для отмены введенной команды на перезагрузку следует нажать 'n'
в диалоге подтверждения.
Синтаксис
reload system
13
