режим. В случае наличия непримененных изменений они будут утеряны при выходе,
поэтому команда снабжена диалогом подтверждения.
Синтаксис
end
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p15
Командный режим
ANY-CONFIG
Пример
0/ME5100:example_router01(config-isis)# end
0/ME5100:example_router01#
3.9. exit
Данной командой осуществляется переход вверх по уровням конфигурации, вплоть до
глобального режима. При переходе в глобальный режим и при наличии непримененных
изменений эти изменения будут утеряны, поэтому команда снабжена диалогом
подтверждения.
Синтаксис
exit
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p15
Командный режим
ANY-CONFIG
Пример
0/ME5100:example_router01(config-level)# exit
0/ME5100:example_router01(config-tengigabitethernet)# exit
0/ME5100:example_router01(config-isis)# exit
0/ME5100:example_router01(config)# exit
Uncommitted changes found, commit them before exiting? (y/n/cancel): [cancel] n
0/ME5100:example_router01#
33
