Eltex ME5100 [441/670] Link type
![Eltex ME5100 [441/670] Link type](/views2/1569351/page441/bg1b9.png)
Отрицательная форма команды удаляет настройку.
Синтаксис
if-msti MSTI_ID
no if-msti
Параметры
• MSTI_ID — числовой идентификатор MSTI (1..4094)
Необходимый уровень привилегий
p10
Командный режим
config-spanning-tree-mstp-interface-tengigabitethernet
Пример
0/ME5100:example_router01(config)# spanning-tree mstp interface tengigabitethernet
0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# if-msti 1
0/ME5100:example_router01(config-if-msti)#
16.5. link-type
Команда задает тип STP интерфейса
Отрицательная форма команды возврщает тип по умолчанию (point-to-point)
Синтаксис
link-type { multilink | point-to-point }
no link-type
Параметры
• multilink — точка-многоточка
• point-to-point — точка-точка
Необходимый уровень привилегий
p10
Командный режим
config-spanning-tree-mstp-interface
config-spanning-tree-rstp-interface
config-spanning-tree-stp-interface
Пример
420
