source-address any source-address IPv4_WILDCARD
no source-address
Параметры
• any — любой адрес RP
• IPv4_WILDCARD — префикс в формате wildcard
Необходимый уровень привилегий
p10
Командный режим
config-router-msdp-peer-sa-filter-in
config-router-msdp-peer-sa-filter-out
config-router-msdp-vrf-peer-sa-filter-in
config-router-msdp-vrf-peer-sa-filter-out
Пример
0/ME5200:example_router01(config)# router msdp
0/ME5200:example_router01(config-msdp)# peer 10.0.0.1
0/ME5200:example_router01(config-peer)# sa-filter in 1
0/ME5200:example_router01(config-in)# source-address 10.0.0.0/0.0.0.255
0/ME5200:example_router01(config-in)#
20.17. vrf
Команда включает протокол MSDP внутри экземпляра VRF и входит в режим его
конфигурирования.
Отрицательная форма команды удаляет конфигурацию MSDP для указанного экземпляра
VRF.
Синтаксис
[no] vrf VRF_NAME
Параметры
• VRF_NAME — строковое имя VRF (1..31)
Необходимый уровень привилегий
p10
Командный режим
config-router-msdp
Пример
472
