![Eltex ME5100 [411/670] Encapsulation mpls mtu](/views2/1569351/page411/bg19b.png)
Командный режим
config-l2vpn-pw-class
Пример
0/ME5100:example_router01(config)# l2vpn pw-class PW1
0/ME5100:example_router01(config-pw-class)# encapsulation mpls control-word preferred
0/ME5100:example_router01(config-pw-class)#
15.6. encapsulation mpls mtu
Данная команда создает в конфигурации параметр, который отвечает за MTU Attachment
circuit.
Отрицательная форма команды возращает значение по умолчанию (0).
Синтаксис
encapsulation mpls mtu NUMBER
no encapsulation mpls mtu
Параметры
• NUMBER — число, которое отвечает за значение MTU.
Необходимый уровень привилегий
p10
Командный режим
config-l2vpn-pw-class
Пример
0/ME5100:example_router01(config)# l2vpn pw-class PW1
0/ME5100:example_router01(config-pw-class)# encapsulation mpls mtu 1600
0/ME5100:example_router01(config-pw-class)#
15.7. encapsulation mpls signaling-type
Данная команда позволяет создать в конфигурации правило, которое отвечает за способ
распространения MPLS-меток для Pseudowire.
Отрицательная форма команды возвращает значение по умолчанию (manual).
Синтаксис
encapsulation mpls signaling-type { manual | pseudowire-id-fec-signaling }
no encapsulation mpls signaling-type
Параметры
