6. УПРАВЛЕНИЕ СИСТЕМНЫМИ ЧАСАМИ
6.1. broadcast-client
Данной командой включается режим приёма широковещательных сообщений NTP-
серверов, при этом устройство работает в качестве NTP-клиента. Если в конфигурации
устройства заданы NTP пиры и серверы, то в широковещательном режиме они
игнорируются.
Использование отрицательной формы команды выключает широковещательный режим.
Синтаксис
[no] broadcast-client
Параметры
Команда не содержит аргументов
Необходимый уровень привилегий
p10
Командный режим
config-ntp-vrf
Пример
0/ME5100:example_router01(config)# ntp vrf mgmt-intf
0/ME5100:example_router01(config-vrf)# broadcast-client
6.2. clock read-calendar
Данная команда синхронизирует значение программных часов системы со значением
аппаратных часов.
Синтаксис
clock read-calendar
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
GLOBAL
Пример
74
