Eltex ME5100 [77/670] Line console session timeout
![Eltex ME5100 [77/670] Line console session timeout](/views2/1569351/page77/bg4d.png)
Командный режим
config
Пример
0/ME5100:example_router01(config)# line console login authentication LOGIN-LIST
5.11. line console session-timeout
Данная команда задает период неактивности подключенного на консольном порту
пользователя, по истечении которого сессия пользователя будет принудительно завершена.
Отрицательная форма команды устанавливает для периода неактивности значение по
умолчанию.
Синтаксис
line console session-timeout TIMEOUT
no line console session-timeout
Параметры
• TIMEOUT — значение таймаута, в минутах, принимает значения от 1 до 1440.
Необходимый уровень привилегий
p15
Командный режим
config
Пример
0/ME5100:example_router01(config)# line console session-timeout 600
5.12. line ssh enable authentication
Команда включает enable-аутентификацию (аутентификацию при переходе на разные
уровни привилегий) подключенных по протоколу SSH пользователей через ранее
сконфигурированный список методов AAA ('aaa authentication enable'). После выполнения
данной команды enable-аутентификация подключенных по протоколу SSH пользователей
будет проводиться по методам, указанным в этом списке.
Отрицательная форма команды возвращает тип аутентификации по умолчанию.
Синтаксис
line ssh enable authentication LISTNAME
no line ssh enable authentication
Параметры
56
