0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# level level-2
0/ME5100:example_router01(config-level)#
12.29. lfa
Данная команда включает поддержку протокола IS-IS IP Loop-Free Alternate Fast Reroute (IS-IS
IP LFA FRR) для данного интерфейса или семейства адресов. При использовании команды на
интерфейсе, для маршрутов данного интерфейса будут расчитываться альтернативные
маршруты.
Отрицательная форма команды отключает поддержку данного протокола для интерфейса
или семейства адресов.
Синтаксис
[no] lfa
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-isis-address-family-ipv4-unicast
config-router-isis-address-family-ipv6-unicast
config-router-isis-interface
config-router-isis-vrf-address-family-ipv4-unicast
config-router-isis-vrf-address-family-ipv6-unicast
config-router-isis-vrf-interface
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# lfa
0/ME5100:example_router01(config-tengigabitethernet)#
IMPORTANT
Механизм LFA работает только для интерфейсов типа point-to-point (см.
команду point-to-point).
12.30. lfa exclude
Команда исключает заданный интерфейс из расчета альтернативных маршрутов.
209
