example_router01 login: admin
Password:
********************************************
* Welcome to ME5100 *
********************************************
Warning:
Ê Firmware upgrade is in progress (consult 'show firmware' for details).
Ê To finalize upgrade type 'firmware confirm'. Otherwise previous version
Ê will be used next time.
0/ME5100:example_router01# show firmware
Tue May 16 17:17:00 2017
Ê Unit Image Running Boot Version Date
Ê --------- ------ -------- ------------- --------------------- ---------------------
Ê 0/ME5100 0 No FALLBACK* 1.5.0.220R 15-May-2017 11:17:03
Ê 0/ME5100 1 Yes TESTING 1.5.0.221R 15-May-2017 23:58:34
0/ME5100:example_router01# firmware confirm
0/ME5100:example_router01# show firmware
Tue May 16 17:17:11 2017
Ê Unit Image Running Boot Version Date
Ê --------- ------ -------- ------------- --------------------- ---------------------
Ê 0/ME5100 0 No 1.5.0.220R 15-May-2017 11:17:03
Ê 0/ME5100 1 Yes * 1.5.0.221R 15-May-2017 23:58:34
3.11. firmware select
Данной командой выбирается образ ПО, с которого будет производиться следующая
загрузка устройства.
На маршрутизаторе имеется два раздела и, соответственно, два образа программного
обеспечения. В каждый момент времени один из образов является активным (с активного
раздела производится загрузка устройства), а другой - альтернативным. Команда позволяет
выбрать в качестве загрузочного один из двух этих разделов. Команда является частью
набора для работы с образами программного обеспечения устройства.
Синтаксис
firmware select { alternate [ confirmed SECONDS ] | current }
Параметры
• alternate — выбор альтернативного образа ПО в качестве временно загрузочного.
Альтернативный образ будет запущен при следующей загрузке устройства. После
загрузки этот образ будет иметь состояние TESTING ("проверка"). Для последующей
установки образа в качестве загрузочного (активного) на постоянной основе следует
воспользоваться командой 'firmware confirm'.
• current — выбор активного образа ПО в качестве загрузочного.
35
