Eltex ME5100 [172/670] Match path type
![Eltex ME5100 [172/670] Match path type](/views2/1569351/page172/bgac.png)
Командный режим
config-router-ospfv2-redistribution-bgp
config-router-ospfv2-redistribution-connected
config-router-ospfv2-redistribution-isis
config-router-ospfv2-redistribution-local
config-router-ospfv2-redistribution-static
config-router-ospfv2-vrf-redistribution-bgp
config-router-ospfv2-vrf-redistribution-connected
config-router-ospfv2-vrf-redistribution-isis
config-router-ospfv2-vrf-redistribution-local
config-router-ospfv2-vrf-redistribution-static
config-router-ospfv3-redistribution-bgp
config-router-ospfv3-redistribution-connected
config-router-ospfv3-redistribution-isis
config-router-ospfv3-redistribution-local
config-router-ospfv3-redistribution-static
config-router-ospfv3-vrf-redistribution-bgp
config-router-ospfv3-vrf-redistribution-connected
config-router-ospfv3-vrf-redistribution-isis
config-router-ospfv3-vrf-redistribution-local
config-router-ospfv3-vrf-redistribution-static
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# redistribution connected CONNECTED
0/ME5100:example_router01(config-connected)# match nexthop 10.1.1.1/32
0/ME5100:example_router01(config-connected)#
11.33. match path-type
Данная команда позволяет создать в конфигурации фильтр, с помощью которого можно
отфильтровать используемые в редистрибуции из Border Gateway Protocol (BGP) или из
Intermediate System to Intermediate System (IS-IS) маршруты по их типу.
Отрицательная форма команды возвращает значение по умолчанию (none).
Синтаксис
match path-type { bgp-external | bgp-internal | none }
match path-type { isis-level1-external | isis-level1-internal | isis-level2-external | isis-
level2-internal | none }
no match path-type
Параметры
• bgp-external — External BGP (eBGP) маршрут;
• bgp-internal — Internal BGP (iBGP) маршрут;
• isis-level1-external — IS-IS Level 1 маршрут, полученный через редистрибуцию;
151
