Eltex ME5100 [98/670] Minpoll
![Eltex ME5000 [98/670] Minpoll](/views2/1569351/page98/bg62.png)
Командный режим
config-ntp-vrf-peer-ipv4
config-ntp-vrf-server-ipv4
Пример
0/ME5100:example_router01(config)# ntp vrf default
0/ME5100:example_router01(config-vrf)# server ipv4 192.168.16.36
0/ME5100:example_router01(config-ipv4)# maxpoll 15
6.7. minpoll
Данная команда устанавливает минимальное значение интервала времени между
отправкой сообщений NTP-серверу.
Использование отрицательной формы команды устанавливает значение по умолчанию (6,
что соответствует 64 секундам).
Синтаксис
minpoll INTERVAL_EXPONENT
no minpoll
Параметры
• INTERVAL_EXPONENT — минимальное значение интервала опроса (степень).
Параметр команды используется как показатель степени двойки при вычислении
длительности интервала в секундах. Сам интервал вычисляется путем возведения
двойки в степень, заданную параметром команды. Принимает значения 4..17.
Необходимый уровень привилегий
p10
Командный режим
config-ntp-vrf-peer-ipv4
config-ntp-vrf-server-ipv4
Пример
0/ME5100:example_router01(config)# ntp vrf default
0/ME5100:example_router01(config-vrf)# server ipv4 192.168.16.36
0/ME5100:example_router01(config-ipv4)# minpoll 3
6.8. ntp vrf
Команда включает протокол ntp в заданном vrf и переходит в режим его конфигурирования
Отрицательная форма команды отключает протокол ntp в заданном vrf и удаляет всю
связанную конфигурацию
77
