11.36. maximum-paths
Команда задает максимальное число ECMP маршрутов устанавливаемых в OSPF RIB
Отрицательная форма команды возвращает значение по умолчанию (5)
Синтаксис
maximum-paths NUM
no maximum-paths
Параметры
• NUM — количество ECMP маршрутов (1..8)
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2
config-router-ospfv2-virtual-if
config-router-ospfv2-vrf
config-router-ospfv2-vrf-virtual-if
config-router-ospfv3
config-router-ospfv3-virtual-if
config-router-ospfv3-vrf
config-router-ospfv3-vrf-virtual-if
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# maximum-paths 8
0/ME5100:example_router01(config-ospfv2)#
11.37. metric
Данная команда устанавливает значение метрики интерфейса.
Отрицательная форма команды возвращает значение метрики по умолчанию (1).
Синтаксис
metric METRIC
[no] metric
Параметры
• METRIC — значение метрики для интерфейса (0..65535).
Необходимый уровень привилегий
p10
154
