![Eltex ME5000 [492/670] Shutdown](/views2/1569351/page492/bg1ec.png)
Необходимый уровень привилегий
p10
Командный режим
config-router-msdp-peer
config-router-msdp-vrf-peer
Пример
0/ME5200:example_router01(config)# router msdp
0/ME5200:example_router01(config-msdp)# peer 10.0.0.1
0/ME5200:example_router01(config-peer)# sa-filter out 1
0/ME5200:example_router01(config-in)#
20.15. shutdown
Команда позволяет административно отключить сессию с соседом, не удаляя всей
соответствующей конфигурации.
Отрицательная форма команды активирует сессию.
Синтаксис
[no] shutdown
Параметры
Команда не содержит аргументов
Необходимый уровень привилегий
p10
Командный режим
config-router-msdp-peer
config-router-msdp-vrf-peer
Пример
0/ME5200:example_router01(config)# router msdp
0/ME5200:example_router01(config-msdp)# peer 10.0.0.1
0/ME5200:example_router01(config-peer)# shutdown
20.16. source-address
Команда включает фильтрацию SA сообщений по адресу MSDP-пира.
Отрицательная форма команды отключает фильтрацию
Синтаксис
471
