Eltex ME5100 [73/670] Aaa authentication login
![Eltex ME5100 [73/670] Aaa authentication login](/views2/1569351/page73/bg49.png)
0/ME5100:example_router01(config)# aaa authentication enable ENABLE-LIST
0/ME5100:example_router01(config-enable)#
5.4. aaa authentication login
Данная команда создает в конфигурации устройства именованный список методов,
используемых для аутентификации при входе в систему и позволяет перейти в режим
настройки этого списка (config-aaa-authentication-login).
Список методов, в сконфигурированной последовательности, будет применен при
выполнении аутентификации операторов устройства. Переход к следующему методу
списка осуществляется только при невозможности воспользоваться предыдущим методом
(например, в случае недоступности AAA-сервера, на который ссылается метод). Если при
проверке метода будет получен четкий отказ от соответствующего источника (например,
RADIUS Access-reject), то аутентификация будет считаться неудавшейся и перехода к
следующему методу производиться не будет.
Отрицательная форма команды удаляет соответствующий именованный список методов.
Синтаксис
[no] aaa authentication login LISTNAME
Параметры
• LISTNAME — имя списка методов.
Необходимый уровень привилегий
p15
Командный режим
config
Пример
0/ME5100:example_router01(config)# aaa authentication login LOGIN-LIST
0/ME5100:example_router01(config-login)#
5.5. acct-port
Данной командой настраивается UDP-порт, который будет использоваться при отправке
сообщений AAA-учета на удаленный RADIUS-сервер. Команда используется внутри раздела
настройки RADIUS-сервера (config-aaa-radius-server-host). Отрицательная форма команды
устанавливает номер используемого порта в значение по умолчанию.
Синтаксис
acct-port PORT
no acct-port
52
