13.39. ebgp-multihop
Команда включает возможность устанавливать сессию с соседом, находящимся на
удалении до 255 хопов, при этом TTL пакетов выставляется равным 255. Возможная
удаленность соседа может быть задана модификатором ttl.
Отрицательная форма команды возвращает поведение по умолчанию, сессия может
устанавливаться только с соседом из connected сети (TTL 1). Отрицательная форма команды
с модификатором ttl возвращает значение параметра по умолчанию (255).
Синтаксис
[no] ebgp-multihop
ebgp-multihop ttl TTL
no ebgp-multihop ttl
Параметры
• TTL - количество прыжков до соседа. Диапазон допустимых значений: 1..255.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-neighbor
config-router-bgp-peergroup
config-router-bgp-vrf-neighbor
config-router-bgp-vrf-peergroup
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# neighbor 10.0.0.10
0/ME5100:example_router01(config-neighbor)# ebgp-multihop
0/ME5100:example_router01(config-neighbor)# ebgp-multihop ttl 64
0/ME5100:example_router01(config-neighbor)# no ebgp-multihop ttl
0/ME5100:example_router01(config-neighbor)# no ebgp-multihop
13.40. enforce-first-as disable
Команда аналогична команде bgp enforce-first-as disable из режима конфигурации router
bgp, только применяется для заданного соседа.
Синтаксис
enforce-first-as disable
no enforce-first-as disable
Параметры
Команда не содержит аргументов.
282
